Linear guide rail and block system is a kind of rolling guide, which is an infinite rolling cycle between the steel ball and the guide rail, so that the load platform can easily move linearly along the guide rail with high precision and reduce the friction coefficient,to achieve high positioning accuracy. The design of the final unit between the slider and the guide rail enables the linear guide to bear the load in all directions, such as up, down, left and right. The patented reflow system and the simplified structural design make the linear guide have smoother and less noisy motion.
Four-row linear recirculating ball bearing and guideway assemblies represent the most extensive and complex group within the range of monorail guidance systems. They are used where linear guidance systems with high load carrying capacity and rigidity must move heavy loads with high running and positional accuracy as well as low friction. The guidance systems are preloaded and are suitable for long, unlimited stroke lengths.
Depending on the operating conditions, accelerations up to 150 m/s2 and speeds up to 360 m/min are possible. Where designs are planned with extensive use of accessories and travel speeds >180 m/min, please contact us.
The units are available in full complement design and with Quad Spacers. A guidance system comprises at least one carriage with rolling elements, a guideway and two-piece plastic closing plugs. The four-row linear recirculating ball bearing and guideway assemblies are supplied with initial greasing as standard.
Four-row linear recirculating ball bearing and guideway assemblies are linear guidance systems of X-life quality. They are characterised by improved technological characteristics, increased robustness and a longer operating life.
Application of linear guide and blocks:
Grinding machine, milling machines, lathes, drilling machine, and comprehensive processing machines, discharge manufacturing machine, boring machine, line cutting machine, precise measurement instrument, woodworking machinery, handling machine, and the shipping device.
